Twilight Switches

New View larger

CELULA CREPUSCULAR MODULAR LUNA 122 top3 2CAN IP55

THEBEN
001.1220130

Delivery in 2 to 3 weeks time

PVP s/IVA: 198,00€

More info

Name:TWILIGHT SWITCH LUNA 122 top2 2CAN IP55

Description
- Twilight switch with integrated weekly timer
- External light sensor included in delivery
- Variable lux values can be set for each day
- for each day of the week
- Fixed ON and OFF times (e.g. nighttime interruption)
- can be programmed independent of brightness
- 2 special programmes with yearly function
- (e.g. 24.12.2007 to 6.01.2008): Variable lux values and switching times can be set for each special program
- DCF77 radio controlled via external antenna
- 2 channels
- Foliday and public holiday program with yearly function
- for fixed and Easter-dependent public holidays
- Different summer/winter time rules can be selected or freely defined
- Channel-independent operaing hours counter
- 2 external contol inputs
- Switching brightness digitally adjustable
- Adjustable On and Off switching delay
- to avoid switching errors caused by lightninh, car headlights etc. Preset 1 minute
- Switching brightness and switching delay can be set separately for switching On and Off
- Onscreen display of channel and switching status as well as current lux value
- DuoFix spring terminals
- for 2 conductors per connection terminal
- Zero-cross switching for relay-saving switching and high lamp loads (not with 24 V devices)
- Up to 4 sensors can be attached
- Up to 10 devices can be connected to a digital sensor
- Interface for OBELISK top2 memory card (PC programming)
- 2. insertable switching program
- Copying programs
- Storing programs
- External light sensor included in delivery
- Extended brightness range
- Permanent switching ON/OFF
- Test function
- (Permanent ON) to check the installation independently of set brightness value
- Switching preselection
- Display back light (can be turned off)
- PIN coding
- External input
- for switches or buttons
- Operating hour counter
- with reminder function
